The JX125 Double Head CNC Machine is a cutting-edge machine tool that utilizes a central spindle, two Z-axes, two X-axes, and bidirectional drag plate movement for high precision and efficient machining. This machine boasts outstanding features such as high accuracy, high efficiency, and high rigidity.
With dual-end rotation of workpieces, the JX125 Double Head CNC Machine achieves exceptional concentricity, allowing for simultaneous machining of both ends and doubling the productivity. It offers powerful functionalities for machining center holes, threads, internal holes, external circles, end faces, and more on shaft-like components with a concentricity of ≤0.01. For tubular and sleeve-like parts, it can process internal holes, internal threads, and other features on both ends with a concentricity of ≤0.01.
The JX125 Double Head CNC Machine features a slant track layout that ensures high rigidity, high precision, and facilitates chip evacuation. Equipped with a dual-channel system, it offers simple operation and a high degree of intelligence. The adoption of imported linear guides and screws guarantees the precision and stability of the machine. Workpiece clamping can be done hydraulically or pneumatically, providing convenient and quick setups. It also features automatic chip removal, automatic forced lubrication, and clamping accuracy of ≤0.01.
To ensure long-term machining stability, the JX125 Double Head CNC Machine is constructed with high-quality cast iron components using advanced finite element analysis technology for a rational design and optimized layout. These castings are then subjected to secondary aging treatment to guarantee stability during machining.
Both the X-axis and Z-axis screws utilize precision ball screws along with a scientific pre-stretching assembly process, resulting in minimal thermal deformation and high transmission accuracy.
The supporting bearings for the screws are sourced from well-known brands, while the locking nuts for the screws are high-precision, improving the support and clamping accuracy of the screws and further enhancing the machining precision of the machine tool.
The JX125 Double Head CNC Machine is designed to provide exceptional precision and longevity, offering reliable performance and an extended service life even under continuous usage.
